Bon BSM-173N3G 17″ 3G-SDI/HDMI Broadcast and Production Monitor

EGP600.00

Monitor Full HD 1080p signals in their native resolution with the BON BSM-173N3G 17″ 3G-SDI/HDMI Broadcast and Production Monitor. SD and HD signals are accepted through the SDI, HDMI, DVI, and analog video inputs and are displayed accurately on

Key Features
  • 17″ 1920 x 1080 LCD Display
  • Supports NTSC, PAL, and HD
  • SDI, HDMI, DVI, and Analog Inputs
  • 160°/140° H/V Viewing Angle
  • Built-In Signal Analysis
  • Aspect Ratio Markers and Focus Assist
  • Timecode and Audio Level Display
  • 12 VDC & 110/220 AC Power

Bon BSM Monitor Overview

Monitor Full HD 1080p signals in their native resolution with the BON BSM-173N3G 17″ 3G-SDI/HDMI Broadcast and Production Monitor. SD and HD signals are accepted through the SDI, HDMI, DVI, and analog video inputs and are displayed accurately on the color-calibrated 1920 x 1080 LED-backlit LCD panel. Built-in monitoring tools such as waveform, vectorscope, and false color can be used to analyze your video and make adjustments accordingly. Other broadcast-ready features include tally display, aspect ratio markers, audio level display, and closed caption support. Standard mains power via IEC and DC power via four-pin XLR are accepted for use in the studio or in the field.

Monitoring Tools
Waveform/vectorscope
False color
Timecode display
Exposure range check
AFD and V-chip (SDI Only)
R/G/B or gray-only display
Pixel-to-pixel view
Freeze frame
Tally display
Menu settings transfer with USB
Focus assistance
Closed caption (CEA-608/708)
Audio level meter, 8 to 16-channel
UMD/IMD mode (supports TSL 4.0)
Aspect ratio markers
H/V delay
Zero/under/over-scan
R/G/B/W internal patterns
Monitor controllable via Ethernet
SDI and CVBS PiP
Rack and VESA mountable (with separately available kits)
